FEATURES
- 80 PLUS® Gold certified
- Micro Tolerance Load Regulation (0.5 %)
- Cable-free Connection Design
- Premium Hybrid Fan Control - Fanless until 40 % load
- Multi-GPU setup
- Gold plated connectors
- 12 years warranty
SPECIFICATIONS
| Model | SSR-750GD |
| Technical Specifications | |
| 80PLUS® | Gold |
| Cybenetics Efficiency Level | ETA-A |
| Cybenetics Noise Level | LAMBDA-S++ |
| Form Factor | Intel ATX 12 V |
| Dimensions | 170 mm (W) x 150 mm (L) x 86 mm (H) |
| Fan Information | |
| Fan Size | 135 mm |
| Fan Control | Premium Hybrid Fan Control |
| Fan Bearing | Fluid Dynamic Bearing |
| Life Expectancy | 50,000 hours at 40 °C, 15 % - 65 % RH |
| Cable Information | |
| Modularity | Fully Modular |
| Cable type | Flat black cables |
| Electrical Features | |
| Operating Temperature | 0 - 50 °C (derating from 100 % to 80 % from 40 °C to 50 °C) |
| MTBF @ 25 °C, excl. fan | 150,000 hours |
| AC Input | Full Range |
| Protection | OPP, OVP, UVP, OCP, OTP, SCP |
| Safety and Environmental | |
| Safety and EMC | cTUVus, TUV, CB, CCC, BSMI, EAC, CE |
| Environmental Compliance | Energy Star, RoHS, WEEE, ErP Lot 6, REACH |
| Warranty | 12 Years |
| Note | ***Features, Price and Specifications are subject to change without notice. |
| Psu | |
| Wattage | 750 Watt |
| Series | PRIME GOLD SERIES |
| Certification | 80 Plus Gold |
| Modular | FULLY MODULAR |
| PCIe Connector (6+2) | 4 |
| SATA Connector | 8 |
| Peripheral (4-Pin) | 3 |
| Warranty | 12 Years |
