Features
- ImagePerfect™ firmware supports 24×7 surveillance-optimized workloads tunedto record ~90% of the time and play back video footage the remaining 10%, andsupports more cameras recording at higher resolutions than traditional drives.
- Workload rating of 180TB/year allows SkyHawk to perform reliably in write-intensivesurveillance systems—3× the workload rating of a desktop-class drive
- NVR-ready design allows drives to maintain performance in RAIDand multi-drive systems, giving customers the flexibility to grow with the booming NVR market and scale their systems when more storage is needed.
- ATA streaming support sustains recordings from up to 64 HD cameras for smooth, uninterrupted footage.
- Up to 10TB or over 2000 hours of HD video storage supports an increased numberof cameras and helps to ensure longer data retention periods are met.
- 1M hours MTBF, 3-year limited warranty represents an improved total cost of ownership (TCO) with reduced maintenance costs.
- Lower power consumption means a reduction in heat emissions, which improves reliability in surveillance solutions.
- Tarnish-resistant components help protect drive from environmental elements, increasing field reliability.
Specifications
| Standard Model Numbers | ST4000VX007 |
| Interface | SATA 6 Gb/s |
| Features and Performance | |
| Drive Bays Supported | 8+ |
| Cameras Supported | Up to 64 |
| Max. Sustained Transfer Rate OD (MB/s) | 190MB/s |
| Cache (MB) | 64 |
| Reliability/Data Integrity | |
| Tarnish Resistant | Yes |
| Load/Unload Cycles | 300,000 |
| Non-recoverable Read Errors per Bits Read, Max | 1 per 10E14 |
| Power-On Hours per Year (24×7) | 8,760 |
| Workload Rate Limit (WRL) | 180 |
| Mean Time Between Failures (MTBF) (hours) | 1M |
| Power Management | |
| Startup Current, Typical (12V, A) | 1.8 |
| Average Operating Power (W) | 5.5 W |
| Idling Average (W) | 3.2 W |
| Standby Mode/Sleep Mode, Typical (W) | 0.25/0.25 |
| Voltage Tolerance (5 V) | ±5% |
| Voltage Tolerance (12 V) | ±10% |
| Environmental/Temperature | |
| Operating (ambient, min °C) | 0 |
| Operating (drive case, max °C) | 70 |
| Non-operating (ambient, min °C) | -40 |
| Physical | |
| Height (mm/in, max) | 26.11 mm/1.028 |
| Width (mm/in, max) | 101.85 mm/4.01 |
| Depth (mm/in, max) | 146.99 mm/5.787 |
| Weight (lb/g) | 635 g/1.4 lb |
| Carton Unit Quantity | 20 |
| Cartons per Pallet / Cartons per Layer | 40/8 |
| Warranty | 3 Years |
| Note | ***Features, Price and specifications are subject to change without notice. |
| HARD DRIVES | |
| CAPACITY | 4TB |
| SERIES | SKYHAWK |
| FORM FACTOR | 3.5 INCH |
