FEATURES
- 3D TLC NAND — Increased density is the key to supporting broader workloads, ultra-responsive multi-tasking and an overall faster system.
- 20X faster than a hard drive1 — With incredible read/write speeds, the A1000 will increase the speed and performance of your system.
- Ideal for home cinema PCs and mini PCs — The single-sided M.2 2280 SSD makes it ideal for home cinema PCs and mini PCs with limited space. Integrates easily into designs with M.2 connectors.
- Multiple capacities — Available in a range of capacitiy 240GB to meet your data storage requirements
SPECIFICATIONS
| Model | SA1000M8/240G |
| Form factor | M.2 2280 |
| Interface | PCIe NVMe™ Gen 3.0 x 2 lanes |
| Capacity | 240GB |
| NAND | 3D TLC |
| Sequential read/write | up to 1,500/800MB/s |
| Random 4K read/write | up to 100,000/80,000 IOPS |
| Power consumption | 0.011748W idle / 0.075623W avg / 0.458W (MAX) read / 0.908W (MAX) write |
| Dimensions | 80mm x 22mm x 3.5mm |
| Operating temperature | 0°C to 70°C |
| Storage temperature | -40°C to 85°C |
| Vibration operating | 2.17G peak (7–800Hz) |
| Vibration non-operating | 20G peak (10–2000Hz) |
| Life expectancy | 1 million hours MTBF |
| Total Bytes Written (TBW) | 150TB |
| Warranty | 5 Years |
| Note | ***Features, Price and Specifications are subject to change without notice. |
| Storage | |
| Category | Internal SSD |
| Series | A1000 |
| Capacity | 240GB |
| Form Factor | M.2 2280 |
| NVMe | Yes |
| Interface | PCIe Gen3 |
| Write Speed | Up to 800 MB/s |
| Read Speed | Up to 1500 MB/s |
| TBW | 150 |
| Warranty | 5 Years |
| Note | Features, Price, Specifications are subject to change without notice. Images used for representation purposes only |
