Features:

• Complies with ATX12V V3.1 & EPS12V V2.92
• Support native PCIe 12V-2x6 connector(850W & 750W)
• Efficiency ≧ 85% at typical load
• Active PFC ≧ 0.9
• Hold up time > 17ms at 80% load
• Japanese electrolytic capacitors
• +12V single-rail design
• +5V&3.3V DC to DC module design
• 120mm hydraulic bearing (HYB) fan
• Flat black ribbon cables
• Complete protection: OCP/OVP/OPP/SCP

New ATX PSU Specifications

Updated ATX 3.1 specifications for the next-generation hardware power demands and ensure users get the most stable and cost-optimized performance possible with the highest power efficiency.

80 Plus Bronze Certification

HEXA 85+ PRO Series, 80 PLUS bronze certified, saves energy through its high efficiency up to 85%.

All Black Flat Cables

It gives your system a superior look than ever, and straightforward rather so many entry-level power supplies

Stable DC to DC Output Quality

HEXA 85+ PRO series apply DC to DC modules to improve the reliability and greater compatibility with the quality with low ripple noise to reduce interference of system components, and prolong system lifetime.

+12V Single Rail Design

Designed for power-intensive VGA cards, provides strong power to any overloading condition.

Optimal Cooling

HEXA 85+ PRO series comes with a 120mm quiet hydraulic bearing (HYB) fan and a highly efficient ventilation fan guard to guarantee low noise operations without compromising its cooling efficiency.

Japanese Electrolytic Capacitors

Japanese electrolytic capacitors ensures safety on spare parts for prolonged lifespan and reliability.

Supports High-end Motherboard

For gaming enthusiast, the HEXA 85+ PRO 750W featured dual CPU power connectors for high-end motherboards and stable CPU power delivery.

Connectors

• MB 24 PIN: 1
• CPU 4+4 PIN: 2
• PCIe 12V-2x6: 1
• PCIe 6+2 PIN: 2
• SATA: 8
• Molex: 2
• Floppy: 1

Specification

• Model: HA2-750,Gen5
• Rated Output Power: 750W
• Form Factor: ATX
• 80 PLUS Certification: 80 PLUS Bronze
• Input Voltage: 100-240V
• Input Current: 10-5A
• Input Frequency: 50-60Hz
• PFC: Active PFC
• Efficiency: ≥85% at typical load
• Fan Type: Hydraulic Bearing (HYB) Fan, 120mm
• Protection: OCP/OVP/OPP/SCP
