SPECIFICATIONS
| Model | DE580 |
| Type | ATX 12V V2.31 |
| Dimension | 150×140×86mm (W x L x H) |
| Output Capacity | 450W |
| Input Voltage | 160~240V |
| Input Current | 4A |
| Input Frequency Range | 47~63Hz |
| Fan Size | 120mm silent fan with PWM function |
| Power Good Signal | 100-500ms |
| Hold Up Time | >16ms |
| Protection | OVP / UVP / SCP / OPP |
| Operation Temperature | 0~40°C |
| Regulatory | CE / CB / EAC / TUV |
| MTBF | 100,000 Hours |
| Warranty | 3 Years |
| Note | ***Features, Price and Specifications are subject to change without notice. |
FEATURES
- Compliant to Intel ATX 12V V2.31.
- Supports a wide range of input voltage (160-264V AC), allowing the system to provide stable performance despite an unstable circumstance.
- 120 mm quiet PWM-capable fan.
- Single channel +12V output.
- CircuitShieldTM Over Voltage Protection(OVP), Under Voltage Protection(UVP), Short Circuit Protection(SCP), and Over Power Protection(OPP) features.
- Longer cable supports cable management in the middle tower case.
- High reliability with at least 100,000-hour MTBF.
- Excellent cost-to-performance ratio.
120 mm Smart fan
Excellent performance-to-noise ratio.
Safe and durable with long service life
Multiple protective measures for up to 100,000 hours of use.
| Psu | |
| Wattage | 580 Watt |
| Series | DE SERIES |
| PCIe Connector (6+2) | 1 |
| SATA Connector | 4 |
| Peripheral (4-Pin) | 3 |
