SPECIFICATIONS
| Model | DA550 |
| Type | ATX 12V V2.31 |
| Certifications | 80PLUS Bronze |
| Dimension | 150×140×86mm (W x L x H) |
| Output Capacity | 550W |
| Input Voltage | 100~240V |
| Input Current | 10A |
| Input Frequency Range | 47~63Hz |
| Fan Size | 120mm Silent Fan |
| PFC | Active PFC (>0.9) |
| Power Good Signal | 100-500ms |
| Hold Up Time | >16ms |
| Efficiency | >85% Under Typical Load |
| Protection | OVP / SCP / OTP/UVP/OPP |
| Operation Temperature | 0~40°C |
| Regulatory | CE / FCC / CCC / CB / EAC / TUV |
| MTBF | 120,000 Hours |
| Warranty | 3 Years |
| Note | ***Features, Price and Specifications are subject to change without notice. |
FEATURES
- Compliant Intel ATX12V v 2.31
- The integrated Active PFC+ PWM Combo Controller will increase the efficiency of exchange and make PFC higher than 99%
- 80 PLUS® Bronze certified — up to 85% efficient
- 120mm silent fan with PWM function
- The longer cable design supports cable management perfectly
- Double-Layer EMI Filter protects from electromagnetic interference & restrains noise
- Intelligentized eco-friendly chipset, consume < 1W in its off-mode, compliant Erp standard
- CircuitShield™ —OVP, UVP, SCP, OPP
- Supports Multi-Way SLI / CrossFire + Multi-Core CPUs
- High reliability with an MTBF of at least 120,000 hours of use
DA550 is certified with 80 plus bronze with up to 87% electrical efficiency enabling lower heat generation and lower operation cost. Outstanding and stable performance makes it one of the ideal choices for multi-purpose usage. Double layer EMI filters protect from magnetic interference and restrains noise while operating.
Silent and High Performance Fan
120mm silent fan with PWM function to provide incredible performance-noise ratio.
| Psu | |
| Wattage | 550 Watt |
| Series | DA SERIES |
| Certification | 80 Plus Bronze |
| PCIe Connector (6+2) | 2 |
| SATA Connector | 5 |
| Peripheral (4-Pin) | 3 |
