ASRock USB 3.2 Gen2 -

• ASRock Front Panel Type-C USB 3.2 Gen2 Header (10 Gb/s) -
• ASRock USB 3.2 Gen2x2 Type-C Port (20 Gb/s) -
• ASRock USB 3.2 Gen2 Type-A Port (10 Gb/s)

ASRock Super Alloy -

• Premium Power Choke -
• 50A Dr.MOS -
• Nichicon 12K Black Caps (100% Japan made high quality conductive polymer capacitors) -
• Sapphire Black PCB - High Density Glass Fabric PCB -
• 8 Layer PCB
• 2.5G LAN
• 802.11ax Wi-Fi 6E
• ASRock Auto Driver Installer
• ASRock Steel Slot
• ASRock Full Coverage M.2 Heatsink
• ASRock Hyper M.2 (PCIe Gen4x4)
• ASRock Full Spike Protection (for all USB, Audio, LAN Ports)

• Supports 14^th, 13^th & 12^th Gen Intel Core Processors (LGA1700)
• Digi Power design
• 8 Power Phase design
• Supports Intel® Hybrid Technology
• Supports Intel® Turbo Boost Max 3.0 Technology

• Dual Channel DDR4 Memory Technology
• 2 x DDR4 DIMM Slots
• Supports DDR4 non-ECC, un-buffered memory up to 5000+(OC)
• Supports ECC UDIMM memory modules (operate in non-ECC mode)
• Max. capacity of system memory: 64GB
• Supports Intel® Extreme Memory Profile (XMP) 2.0

• 256Mb AMI UEFI Legal BIOS with multilingual GUI support
• ACPI 6.0 Compliant wake up events
• SMBIOS 2.7 Support
• CPU Core/Cache, CPU GT, DRAM, VCCIN AUX, +1.05V PROC, +1.8V PROC, +0.82V PCH, +1.05V PCH Voltage Multi-adjustment

• Intel Xe Graphics Architecture (Gen 12)
• Dual graphics output: support HDMI and DisplayPort 1.4 ports by independent display controllers
• Supports HDMI 2.1 TMDS Compatible with max. resolution up to 4K x 2K (4096x2160) @ 60Hz
• Supports DisplayPort 1.4 with DSC (compressed) max. resolution up to 8K (7680x4320) @ 60Hz / 5K (5120x3200) @ 120Hz
• Supports HDCP 2.3 with HDMI 2.1 TMDS Compatible and DisplayPort 1.4 Ports

• 7.1 CH HD Audio (Realtek ALC897 Audio Codec)
• Supports Surge Protection
• Nahimic Audio

• 1 x 2.5 Gigabit LAN 10/100/1000/2500 Mb/s (Dragon RTL8125BG)
• Supports Dragon 2.5G LAN Software
• Smart Auto Adjust Bandwidth Control
• Visual User Friendly UI
• Visual Network Usage Statistics
• Optimized Default Setting for Game, Browser, and Streaming Modes
• User Customized Priority Control
• Supports Wake-On-LAN
• Supports Lightning/ESD Protection
• Supports Energy Efficient Ethernet 802.3az
• Supports PXE 1 x Gigabit LAN 10/100/1000 Mb/s (Intel® I219V)
• Supports Wake-On-LAN
• Supports Lightning/ESD Protection
• Supports Energy Efficient Ethernet 802.3az
• Supports UEFI PXE

• - 802.11ax Wi-Fi 6E Module
• Supports IEEE 802.11a/b/g/n/ax
• Supports Dual-Band 2x2 160MHz with extended 6GHz band support
• 2 antennas to support 2 (Transmit) x 2 (Receive) diversity technology
• Supports Bluetooth + High speed class II
• Supports MU-MIMO

CPU: -

• 1 x PCIe 5.0 x16 Slot (PCIE1), supports x16 mode

Chipset: -

• 1 x Vertical M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module and Intel® CNVi (Integrated WiFi/BT)

CPU: -

• 1 x Hyper M.2 Socket (M2_1, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode

Chipset: -

• 1 x Hyper M.2 Socket (M2_2, Key M), supports type 2280 SATA3 6.0 Gb/s & PCIe Gen4x4 (64 Gb/s) modes
• 4 x SATA3 6.0 Gb/s Connectors

• Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
• Supports RAID 0, RAID 1 and RAID 5 for M.2 NVMe storage device

• 1 x RGB LED Header
• 1 x Addressable LED Header
• 1 x CPU Fan Connector (4-pin)
• 1 x Chassis Fan Connector (4-pin)
• 1 x Chassis/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)
• 1 x 24 pin ATX Power Connector
• 1 x 8 pin 12V Power Connector (Hi-Density Power Connector)
• 1 x Front Panel Audio Connector
• 1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD Protection)
• 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) (Supports ESD Protection)
• 1 x Front Panel Type C USB 3.2 Gen2x2 Header (Supports ESD Protection)

• 2 x Antenna Ports
• 1 x HDMI Port
• 1 x DisplayPort 1.4
• 4 x USB 3.2 Gen2 Ports (10 Gb/s) (Supports ESD Protection)
• 1 x USB 3.2 Gen2x2 Type-C Port (20 Gb/s) (Supports ESD Protection)
• 2 x USB 2.0 Ports (Supports ESD Protection)
• 2 x RJ-45 LAN Ports with LED (ACT/LINK LED and SPEED LED) - 1 x BIOS Flashback Button
• HD Audio Jacks: Line in / Front Speaker / Microphone

Software -

• ASRock Motherboard Utility (A-Tuning)
• ASRock Dragon 2.5G LAN Software
• ASRock Polychrome SYNC

UEFI -

• ASRock EZ Mode
• ASRock Full HD UEFI
• ASRock Auto Driver Installer
• ASRock My Favorites in UEFI
• ASRock Instant Flash
• ASRock Internet Flash
• ASRock Easy RAID Installer

Drivers, Utilities, AntiVirus Software (Trial Version)

• Quick Installation Guide, Support CD, I/O Shield
• 2 x SATA Data Cables
• 2 x ASRock WiFi 2.4/5/6 GHz Antennas
• 2 x Screws for M.2 Sockets

• Fan Tachometer: CPU, Chassis, Chassis/Water Pump Fans
• Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, Chassis, Chassis/Water Pump Fans
• Fan Multi-Speed Control: CPU, Chassis, Chassis/Water Pump Fans
• Voltage monitoring: CPU Vcore, +12V, +5V, +3.3V

• Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.0 cm x 17.0 cm
• 8 Layer PCB

• FCC, CE
• ErP/EuP ready (ErP/EuP ready power supply is required)
