Specification
|
Application |
Client PCs |
|
Capacity |
1,024 GB |
|
Form Factor |
2.5 inch |
|
Interface |
SATA 6 Gb/s Interface, compatible with SATA 3 Gb/s & SATA 1.5 Gb/s interface |
|
Dimension (WxHxD) |
100 x 69.85 x 6.8 (mm) |
|
Weight |
Max 60 g Weight |
|
NAND Type |
Samsung V-NAND 2 bit MLC |
|
Controller |
Samsung MJX Controller |
|
Cache Memory |
Samsung 1 GB Low Power DDR4 SDRAM |
|
TRIM Support |
TRIM Supported |
|
S.M.A.R.T Support |
S.M.A.R.T Supported |
|
GC (Garbage Collection) |
Auto Garbage Collection Algorithm |
|
Encryption Support |
AES 256-bit Encryption (Class 0) TCG / Opal IEEE1667 (Encrypted drive) |
|
WWN Support |
World Wide Name supported |
|
Device Sleep Mode Support |
Yes |
|
Performance |
|
|
Sequential Read |
Up to 560 MB/s Sequential Read * Performance may vary based on system hardware & configuration |
|
Random Write (4KB, QD32) |
Up to 90,000 IOPS Random Write * Performance may vary based on system hardware & configuration |
|
Sequential Write |
Up to 530 MB/s Sequential Write * Performance may vary based on system hardware & configuration |
|
Random Read (4KB, QD1) |
Up to 11,000 IOPS Random Read * Performance may vary based on system hardware & configuration |
|
Random Read (4KB, QD32) |
Up to 100,000 IOPS Random Read * Performance may vary based on system hardware & configuration |
|
Random Write (4KB, QD1) |
Up to 43,000 IOPS Random Write * Performance may vary based on system hardware & configuration |
|
Environment |
|
|
Power Consumption |
Average: 2.2 W*Maximum: 4.5 W (Burst mode)* Actual power consumption may vary depending on system hardware & configuration |
|
Reliability (MTBF) |
2 Million Hours Reliability (MTBF) |
|
Operating Temperature |
0 - 70 °C Operating Temperature |
|
Shock |
1,500 G & 0.5 ms (Half sine) |
|
Software |
|
|
Management SW |
Magician Software for SSD management |
|
Installation Kit |
Not Available |
|
Warranty |
5 Years |
|
Note |
***Features, Price and Specifications are subject to change without notice. |
Features
The SSD to trust
Get industry-leading reliability with the 860 PRO. Powered by the latest V-NAND technology and a robust algorithm-based controller, it readily handles heavy workloads of high-end PCs, workstations and NAS (Network Attached Systems) to give lasting assurance to gamers, IT and creative professionals.
Enhanced performance
Speeds are more consistent and sustained, even with heavy workloads and multiple tasks. The 860 PRO performs at sequential write speeds up to 530 MB/s with the best combination of the latest V-NAND and a refined controller, delivering sequential read speeds up to 560 MB/s.
Fierce endurance
Under heavy workloads, endurance is everything. Safely store and render 4K videos and 3D data used by the latest applications, up to 8x higher TBW* than the previous 850 PRO. The latest V-NAND technology gives you industry-leading endurance backed by a 5-year or up to 4,800 TBW limited warranty.
Smart compatibility
Benefit from faster, more fluid communication with your host system. The refined ECC* algorithm and a new MJX controller generate higher speeds, and the improved queued trim enhances Linux compatibility. Our advanced engineering makes the 860 PRO more compatible with your computing system.
| HARD DRIVES | |
| CAPACITY | 1TB |
| SERIES | 860 PRO |
| FORM FACTOR | 2.5 INCH |
