Nzxt H510 Flow Cabinet (Matte Black)
7.5% Instant Discount on HDFC Credit & Debit Card EMI
- Brand: NZXT
- Product Code: CA-H52FB-01
- Availability: Out Of Stock
Nzxt H510 Flow Cabinet (Matte Black)
Offer Price
₹6,299
(40% off ) ₹10,499
Free Delivery
Check
Delivery is guaranteed as long as our locations stay open according to government regulations.
Features:
This compact mid-tower is an ideal case for high-performance builds and features a perforated front panel for maximized airflow. The H510 is easy to build in and offers flexibility for a variety of ATX parts.
- An optimized perforated top panel delivers increased airflow to your system for improved temperatures
- Iconic cable management bar and uninterrupted tempered-glass side panel
- Cable routing kit with pre-installed channels and straps
- Two Aer F120mm fans and removable filters on all air intakes
- Removable bracket designed for radiators up to 280mm **Case version fans and specs vary from retail version
Specifications:
| Model Number | CA-H52FB-01 |
| Key Specs | |
| Motherboard Support | Mini-ITX, MicroATX, ATX |
| Enclosure Type | Compact Mid-Tower |
| Case Material | SGCC Steel, Tempered Glass |
| Dimensions | |
| Height | 460 mm / 18.11 inches |
| 460 mm / 18.11 inches | 210 mm / 8.26 inches |
| Depth | 428 mm / 16.85 inches |
| Weight | 6.6 kg / 14.5 lb |
| Compatibility & Clearance | |
| Max CPU Cooler Clearance | 165 mm |
| Max GPU Clearance | 360 mm |
| Front Fan & Radiator Clearance | 60 mm |
| Cable Management | 19 - 23 mm |
| Front I/O Ports | |
| USB 3.2 Gen 1 Type-A | 1 |
| USB 3.2 Gen 2 Type-C | 1 |
| Headset Audio Jack | 1 |
| Expansion Slots | |
| Standard | 7 |
| Vertical | - |
| Drive Bays | |
| 2.5" | 2 + 1 |
| 3.5" | 2 + 1 |
| Fan Support | |
| Front | 2 x 120mm / 2 x 140mm |
| Top | 1 x 120mm / 1 x 140mm |
| Rear | 1 x 120mm |
| Filters | All air intake |
| Included Fans | |
| Front | 1 x Aer F 120mm (Case Version) |
| Top | - |
| Rear | 1 x Aer F 120mm (Case Version) |
| Radiator Support | |
| Front | 280mm |
| Rear | 120mm |
| Fan Specs | |
| Model | Aer F 120mm (Case Version) |
| Speed | 1,200 ± 200RPM |
| Airflow | 50.42 CFM |
| Noise | 28 dBA |
| Bearing | Rifle Bearing |
| Fan Connector | 3-pin |
| Warranty | 2 years |
| Note | ***Features, Price and Specifications are subject to change without notice. |
| Cabinet | |
| Cabinet Size | MID-TOWER |
| Color | Black |
| Material | Steel, Tempered Glass |
| Expansion Slots | 7 |
| Motherboard Size | ATX,M-ATX,M-ITX |
| Max CPU Cooler Height | 165mm |
| Max Gpu Length | 360mm |
| Max 3.5" HDD | 3 |
| Max 2.5" SSD | 3 |
| Dust Filters | Top |
| Pre Installed Fans | 2 |
| Max Fan Support | 4 |
| Radiator Support | 280mm,240mm,140mm,120mm |
| Front I/O Panel | USB 3.2, USB Type-C, Headset Audio Jack |
| Warranty | 2 Years |
| Note*** | Features, Price and Specifications are subject to change without notice. Images use for Representation Purpose Only. |
