Lian Li A3-mATX is a Black color Mini Tower Cabinet which accommodates M-ATX and ITX motherboard with 4 slots 415mm large GPU. It also supports up to 360 radiator and 10 x 120mm fans
Features:
- Minimalistic sleek design 26.3L micro form factor chassis
- Side and top panels are designed with steel mesh
- Accommodates M-ATX and ITX motherboard with 4 slots 415mm large GPU
- Supports up to 360 radiator and 10 x 120mm fans
- Supports ATX/SFX/SFX-L and LIAN LI Edge PSU that can be mounted sideways or frontways
- In collaboration with DAN Cases for the case design whereas manufactured and sold by LIAN LI.
The LIAN LI & DAN Cases A3-mATX is a versatile M-ATX mesh PC case that maintains a minimal chassis size while accommodating large components. Thanks to the relocatable PSU bracket, the A3-mATX empowers you to build a powerful and compact PC system tailored to your needs and preferences.
COMPACT DESIGN,MASSIVE POTENTIAL
Dive into the realm of compactness with the A3-mATX, which unlocks the potential of a small form factor PC case.
WELL VENTILATED, MINIMALIST DESIGN
With three sides featuring minimalist mesh panels and a sleek front panel, the A3-mATX combines functionality with style,
making it the perfect touch to your setup.
EFFORTLESS MODULARITY, STREAMLINED BUILDS
The toolless removal of all exterior panels and modular brackets provide easier access for installation and cable management. With a removable bottom dust filter, ensuring the system stays clean and efficient.
VERSATILE COMPATIBILITY, ULTIMATE CUSTOMIZATION
Unleash your creativity with the flexible compatibility A3-mATX without compromising on high-performance, large size components.
FLEXIBLE PSU INSTALLATION
Offers multiple mounting slots for a maximum of 220mm ATX/SFX/SFX-L or LIAN LI Edge PSU for ideal PSU placement to best suit your build requirements.
A DAN CASES COLLABORATION
Combining the design of Daniel Hansen from DAN Cases with LIAN Li’s manufacturing prowess, the collaboration brings the A3-mATX to life.
Specifications:
PRODUCT NAME |
A3-mATX |
MODEL |
G99-A3X-IN |
COLOR |
Black |
CASE TYPE |
MFF (Micro Form Factor) |
DIMENSION |
(D) 443mm x (W) 194mm x (H) 321.5mm (D) 443mm x (W) 194mm x (H) 321.5mm(D) 443mm x (W) 194mm x (H) 306mm(w/o feet) |
CAPACITY |
26.3L |
MATERIAL |
Steel |
MOTHERBOARD SUPPORT |
M-ATX/ITX |
PSU SUPPORT |
ATX/SFX/SFX-L (Max 220mm) |
FAN SUPPORT |
Top: 3 x 120mm Top: 3 x 120mmSide: 3 x 120mm or 2 x 140mmBottom: 3 x 120mmRear: 1 x 120mm |
RADIATOR SUPPORT |
Top: 1 x 360/240mm Side: 1 x 360/280/240mm Bottom: 1 x 240mm (360mm with fan at the bottom) |
DRIVE SUPPORT |
Tray: 2 × 2.5” SSD Tray: 2 × 2.5” SSDBottom: 1 × 2.5” SSD or 1 × 3.5” HDD |
GPU LENGTH CLEARANCE |
Max 415mm |
CPU HEIGHT CLEARANCE |
Max 165mm |
EXPANSION SLOTS |
4 |
I/O PORTS |
1 x Power Button 2 x USB 3.0 TYPE-A 1 x USB 3.1 TYPE-C 1 x Mic 1 x HD Audio |
DUST FILTER |
1 x Bottom |
Warranty |
1 Year |
Note |
*** Features, Price, Specifications are subject to change without notice. |
